TEN-HIGH TIG Welding Tungsten Thoriated 1/16 inch with 2% Thorium, WT20(Red) Thoriated Tungsten Electrodes, 1.6mm x175mm 10pcs Pack by Amazon.co.uk
- • 【SIZE】: Diam 1.6 mm × L 175 mm, TIG Tungsten Electrodes with 2% thorium
- • 【APPLICATION】: It"s used primarily for DC welding and even in high current range on DC it can be very good operation
- • 【START ARC EASILY】: Thorium plays an important role in increasing the electrode emission qualities of thoriated tungsten electrode,which can improve arc starts and allow a higher current carrying capacity.
- • 【LOW BURN-OFF RATE】: Thoriated tungsten electrode operates far below its melting temperature,there is considerably lower rate of consumption and less arc wandering for greater stability.
- • 【GOOD PERFORMANCE】: Fine welding performance,widely used and less welding contamination than other electrodes.
Compare TEN-HIGH TIG Welding Tungsten Thoriated 1/16 inch with 2% Thorium, WT20(Red) Thoriated Tungsten Electrodes, 1.6mm x175mm 10pcs Pack with other products:
Description
1. In the welding area,WT20 becoming the most widely used electrodes today.
2.In the process of production,thorium is evenly dispersed throughout Thoriated tungsten electrode and such evenness makes it possible for electrode to maintain a sharpened edge of the ideal electrode shape for welding thin steel.
Application:
Thoriated Tungsten electrode is used primarily for DC welding of carbon steel, stainless steels,nickel alloys,titanium and so on.
Package including:
10pcs 2%\xa0thoriated tungsten electrode(Diam 1.6 mm \xd7 L 175 mm)
Stable arc, large arc breaking gap, low loss, long service life, higher recrystallization temperature and better conductivity
Good electrical conductivity,suitable for DC welding of carbon steel,stainless steel. And allows the electrode to maintain a sharpened edge—the ideal electrode shape for welding thin steel.
Thorium plays an important role in increasing the electrode emission qualities of thoriated tungsten electrode,which can improve arc starts and allow a higher current carrying capacity.
Diameter
1.6mm (1/16")
1.6mm (1/16")
2.0mm (0.079")
2.4mm (3/32")
2.4mm (3/32")
Length
150mm
175mm
175mm
150mm
175mm
End Color
Red
Red
Red
Red
Red
DC Welding
✓
✓
✓
✓
✓
DC(A)---Straight Polarity(-)
60-150
60-150
100-200
150-250
150-250
DC(A)---Reverse Polarity(+)
10-18
10-18
12-20
15-25
15-25
Product information
- Manufacturer:TEN-HIGH
- Part Number:TH-WT20-red
- Product Dimensions:20.6 x 5.21 x 0.79 cm; 99.79 Grams
- Item model number:TH-WT20-red
- Size:Diam 1.6mm×L 175mm
- Shape:Metal
- Item Package Quantity:1
- Batteries included?:No
- Batteries Required?:No
- Item Weight:99.8 g
