BTF-LIGHTING Individually Addressable WS2801 Light LED Strip 5050 SMD RGB 32LEDs/m 3M 9.8ft 96LEDs IP30 Non-Waterproof Black PCB Pixel Light DC5V 4PIN for Living Room Bedroom Kitchen DIY Decoration by Amazon.co.uk
Description
Brand
BTF-LIGHTING
PCB color
black
Angle of view
120\xb0
Gray level
256
IC Type
WS2801 IC ( Model: WS2801 strip 5050rgb chips)
FPCB width
12mm
Input voltage
DC5V
Standard roll length
9.8ft / roll
Life time
more than 50000hrs
Voltage
0.3W / total led 28.8W
Led Qty
32LEDs / m total 96LEDs
Operating temperature
-20℃ ~ + 60℃
Waterproofness level
IP30 Non waterproof
Recommended AC adapter
DC5V6A (30W)
Product Dimensions
L3000mmxW12mmxH2.31mm
Wavelength (nm)
red, 650 nm; Green, 520 nm; Blue, 460nm
Precautions
Using a DC5V voltage greater than 5V will destroy it.
If you need better LED strip performance, you can use an Android / IOS SP105E Bluetooth controller, an SP107E & CSY08 music controller, or a K-1000C programmable controller.
It is preferable to add a DC5V voltage every 15m because the LEDs at the far end of the bar might be weaker because of the extra resistance and voltage drop that occurs when the power goes on. this end of the bar.
Application:
House, Garden, Boat, Discotheques, Bar, KTV Club, Showroom, Architectural Decorative Lighting, Amusement Park, Theater and Aircraft Lighting Environment Cabin, etc.
Package Included:
1 LED strip IP30 WS2801 of 9.8ft.
1x 4-pin connector
Power and controller are not included
Features
Cuttable
Every LED can be cut off,led strip still working after it is cut.
Cut it to the length you just need.
Every pin function
V +: Voltage, connect to + 5V
DO: Control data signal output
DI: Control data signal input
CO: Control clock data signal output
CI: Control clock data signal input
GND: Data and power grounding
Addressable
Using a programmable controller, you can program every led just as you like.
One IC controls one led.
Every led has its own IC chip
Product information
- Colour:Ip30 Non-waterproof
- Brand:BTF-LIGHTING
- Indoor/Outdoor usage:Indoor
- Special feature:Waterproof
- Light source type:LED
- Power Source:Corded Electric
- Light colour:RGB
- Occasion:Wedding, Christmas
- Material:Plastic
- Controller type:Voice Control
- Product Dimensions:14.99 x 9.91 x 1.52 cm; 73.71 Grams
- Item model number:WS28013M32LB30
- Material Type:Plastic
- Size:9.8ft
- Voltage:5 Volts
- Item Weight:73.6 g
