AZDelivery 16 Channel Relay Module DC 12V with Optocoupler Low Level Trigger Relay Module Board compatible with Arduino Including E-Book! by Amazon.co.uk
- • ✅ AZ-Delivery 16 Relay 12V Module with Optocoupler Low Level Trigger is compatible board with 16 relays for max. 50V AC / 5A or 30V DC / 5A is perfect for all kinds of DIY projects and 100% compatible with several applications.
- • ✅ This 16-channel relay module with optocouplers is perfect for driving up to 16 devices with higher current.
- • ✅ The optocouplers on 16 Relay 12V Module serve to transmit the signals between the two galvanically isolated circuits - e.g. your connected device with a higher current. In addition, a LED display is integrated to read the relay output status.
- • ✅ AZ-Delivery 16-Relay 12V Module with Optocoupler Low Level Trigger is equipped with high current relay which can be controlled directly by the microcontroller.
- • ✅ This product includes an E-Book that provides useful information on how to begin your project, it helps with a quick setup and saves time on the configuration process. We provide an array of application examples, full installation guides and libraries.
Description
The relays are often used in remote control, communication, mechatronics, power electronics, etc. They can also be used to drive powerful voltage / current electronics (such as AC or DC motors, AC devices, etc.) from microelectronics (microcontrollers, sensors, etc.)
Details
Optocoupler and diodes to protect the controller.
It is a robust module for many reliable switching operations.
Particularities
Compact design and large capacity: this 16-Relay module can switch high currents up to 5A.
Compared to other relay modules, the AZ-Delivery relays are generously dimensioned to enable long-term work even under unfavourable operating conditions.
With the help of a jumper, you can configure the power supply source.
Technical Data
Type:
16-channel
Dimensions:
180 mm x 90 mm [7 x 3.5in]
Maximum DC:
5A 30V
Maximum AC:
5A 50V
TTL Control Signal:
5V DC
Contact Type:
Both (Normally Closed - NC, Normally open - NO)
Power Supply:
12V DC (additionally required)
Big capacity
Thanks to the ability of the module to switch high currents up to 5A and to work in unfavourable operating conditions, it can be used for a variety of projects.
Breadboard compatible
The module has a socket and a pin header which makes connecting with a breadboard extremely easy and prototyping very pleasant.
Quick-start guide
When buying one of our high-quality products, you will also receive an inclusive e-book for a quick introduction to the world of Microelectronics.
Dimensions:
180 mm x 90 mm
50 x 140mm
55 mm x 75 mm
49 mm x 51 mm
27 mm x 34 mm
Number:
3 Pieces
3 Pieces
3 Pieces
3 Pieces
3 Pieces
High-Level-Trigger:
-
-
-
-
-
Low-Level-Trigger:
✓
✓
✓
✓
✓
Exciting DIY projects
You can find many craft projects in our blogs on the topics of programming and microelectronics. Every week, we present you with new DIY ideas and product applications.
Support from our experts
Find all technical details about these products in our e-books and blog posts. If you have any further questions, please do not hesitate to contact our tech support at your disposal.
Fast and safe shipping
Because client satisfaction and trust are our top priority, we always offer fast, safe, and reliable delivery with the highest quality standards.
Product information
- Manufacturer:AZDelivery
- Part number:1x 16-Relais Module
- Item Weight:249 g
- Package Dimensions:22.5 x 10.1 x 4.1 cm; 249 Grams
- Manufacturer reference:1x 16-Relais Module
- Size:16-Relais
- Item Package Quantity:1
- Batteries included?:No
- Batteries Required?:No
