ELECROW Raspberry Pi Screen, Touch Screen Monitor 5 Inch HDMI Screen Display 800x480 Compatible with Raspberry Pi 4 3B+ 3B 2B BB Black Banana Pi Windows 10 8 7 by Amazon.co.uk
- • 2. The touch screen monitor supports plug and play, 5 fingers capacitive touch, free-driver.
- • 3. Built-in OSD menu adjustment function in this small hdmi monitor, and supports audio output.
Compare ELECROW Raspberry Pi Screen, Touch Screen Monitor 5 Inch HDMI Screen Display 800x480 Compatible with Raspberry Pi 4 3B+ 3B 2B BB Black Banana Pi Windows 10 8 7 with other products:
Description
5-inch HDMI 800 x 480 Capacitive Touch LCD Display
The resolution of the LCD display is 800 x 480, you can configure the resolution via software, the maximum resolution it supports is 1920 x 1080.
It is a USB capacitive touch screen and does not require the driver.
It supports five touch control, besides that, the LCD screen comes with an OSD menu adjustment function.
You can adjust the contrast, brightness, switch button.
Ports and Buttons Instruction
There are 9 interfaces on the back of the screen, one earphone for audio output.
Two Touches Interfaces(USB connector): for power supply and touch output.
One Display Interface: an HDMI interface, for connecting motherboard and LCD.
One Power Interface: it can control the backlight turn on and turn off to save power.
One Return Button: it’s only useful in the OSD menu.
One Right/Down Button: backlight shortcut key.
One Left/Up Button: backlight shortcut key.
One Menu Button: it’s useful in the OSD setting menu, open the OSD/ select key.
Wide Applications
It is compatible with the latest Raspberry Pi 4B, 3B+, BB Black, Banana Pi, and other mini PC.
It can also be used as a gaming monitor and is compatible with game consoles that output HDMI signals.
It supports Raspbian, Ubuntu, WIN 10 IoT systems, and supports single-touch control, when it used as a display for Raspberry Pi.
It supports Windows 7/ 8/ 8.1/ 10 and supports five touch control when it used as a display for PC.
How to Use with /Raspbian/Ubuntu Mate/Win 10 IoT Core System
Step 1, Install Raspbian Official Image
1.Download the latest image from the official download.
2.Install the system according to the official tutorial steps.
Step 2, Modify the \u201cconfig.text\u201d
After the programming of step 1 is completed, open the config.txt file of SD card root directory and add the following code at the end of the file, save and eject SD card safely:
hdmi_force_hotplug=1
max_usb_current=1
hdmi_drive=1
hdmi_group=2
hdmi_mode=1
hdmi_mode=87
hdmi_cvt 800 480 60 6 0 0 0
dtoverlay=ads7846,cs=1,penirq=25,penirq_pull=2,speed=50000,keep_vref_on=0,swapxy=0,pmax=255,xohms=150,xmin=200,xmax=3900,ymin=200,ymax=3900
display_rotate=0
Step 3, Drive the 5-inch Capacitive Touchscreen with Raspberry Pi
Insert the TF card to the Raspberry Pi, connect the Raspberry Pi and LCD by cables.
Connect the USB cable one of the 4 USB ports of Raspberry Pi and connect the other end of the USB cable to the USB port of the LCD.
After that, if the display and touch function is OK, that means drive successfully.
Notice:
Please use a full 5V/2A for power supply. And if you are using with Raspberry Pi 4, please use full 5V/3A for power supply.
HDMI 1 port is not available for Raspberry Pi 4/4B, please use the HDMI 0 when connect a Raspberry Pi 4/4b to the screen.
And please do not use external power for this monitor, otherwise, the touch function will not available.
Package list
5 inch HDMI Display x 1
Copper Screw Bag x 1
Micro USB Cable x 1
HDMI Cable x 1
DVD x 1
Micro HDMI Adapter x 1
Notice:
When you use this monitor with a Raspberry Pi 4, if you use the Raspberry Pi system image after 2021-10-30, such as Bullseye, dtoverlay=vc4-kms-v3d have to be modified to dtoverlay=vc4-fkms-v3d, otherwise, it will fail to start.I
If using Buster, please comment out by adding # in the front of "dtoverlay = vc4-fkms-V3D" or delete this line directly in the config.txt file.
Product Parameters
Size: 5.0 (inch)
Resolution: 800 \xd7 480 (dots)
Touch: Support 5 point capacitive touch
Audio output: support
Dimensions: 121.11\xd795.24(mm)
Weight: 248 (g)
Screen Size
5 inches
5 inches
5 inches
7 inches
7 inches
7 inches
Screen Resolution
800\xd7480
800\xd7480
800\xd7480
1024\xd7600
1024\xd7600
1024\xd7600
Touch Type
Capacitive
Capacitive
Resistive
Capacitive
Capacitive
Capacitive
Driver Installation
Driver Free
Driver Free
Install driver for touch function
Driver Free
Driver Free
Driver Free
Stand
None
Viewing Angle Adjustable Copper Pillars Stand
None
None
Removable Plastic Stand
Removable Stand
Backlight Button
Yes
Yes
Yes
Yes
Yes
None
Audio/Video
Earphone
Speaker
None
None
Earphone & Speaker
Earphone & Speaker
Mount RPI to Monitor
None
Yes
Yes
None
Yes
Yes
Cable Connection
Yes
Cableless Connection Designed for Raspberry Pi
Yes
Yes
Yes
Cableless Connection
Product information
- Screen size:5 Inches
- Brand:ELECROW
- Special feature:Built-in OSD menu adjustment function(adjustable contrast/brightness/saturation, etc), 800X480 resolution, maximum HDMI resolution 1920*1080 us su
- Connectivity technology:USB, HDMI
- Specific uses for product:Gaming
- Resolution:800*480
- Number of HDMI Ports:1
- Display technology:LED
- Mounting type:Wall Mount
- Voltage:5 Volts
- Product Dimensions:12 x 9.5 x 1.2 cm; 260 Grams
- Item model number:AUS25507D-1
- Manufacturer:Elecrow
- Standing screen display size:5 Inches
- Screen Resolution:800*480
- Wattage:10 watts
- Are Batteries Included:No
- Item Weight:260 g
