Digital Multimeter,INFURIDER YF-770D Auto-Ranging 40000 Counts Electrical Tester for DC/AC Voltage and Current,Resistance,Capacitance,Temperature with Auto Backlight by Amazon.co.uk
Description
DC Voltage:
40mV+/-0.5% +5) 400mV/4V/40V/400V(+/-0.1%+2) 1000V(+/-0.1%+5)
AC Voltage:
40mV(+/-0.1%+10) 400mV/4V/40V/400V(+/-0.8%+10) 750V(+/-1.2%+10)
DC Current:
400μA /4000μA /40mA/400mA(+/-1%+10) 4A/20A(+/-1.2%+10)
AC Current:
400μA /4000μA /40mA/400mA(+/-1.2%+10) 4A/20A(+/-1.5%+10)
Resistance:
400ohm(+/-1.0%+10) 4k/40k /400k/4M Ohm(+/-0.5%+10) 40M Ohm(+/-1%+10)
Capacitance:
9.999nF-99.99mF(+/-3.0%+10)
Temperature:
-20~1000/-4~1832(+/-3%+2)
Frequency:
9.999Hz~9.999MHz(+/-0.1%+5)
Duty Cycle:
0.1%~99.9% (+/-2.0%+2)
Features of the multimeter tester:
· High Accuracy: 0.1%+2dgt
· Display: 40000 Counts
· Auto Range:
· Diode Test:
· hFE Test:
· Continuity Buzzer:
· Data Hold:
· Auto Back Light:
· Auto Power Off:
· Function Switch Indicator Lamp:
· NCV:
· True RMS:
· Relative Value:
· Max/Min:
· Bar Graph Display:
· Mechanical Protection:
Package Include
1 * Digital Multimeter
1 * Test Leads (Red&Black)
1 * Carrying Case
1 * 9V(6F22) Battery
1 * K-Type Thermocouple
1 * User Manual
Product information
- Brand:INFURIDER
- Power source:Battery Powered
- Style:Modern
- Colour:5.770D High Precision Multimeter
- Item weight:350 Grams
- Manufacturer:INFURIDER
- Package Dimensions:22.9 x 17.9 x 6.7 cm; 350 Grams
- Item model number:YF-770D
- Manufacturer part number:YF-770D
- Item Weight:350 g
