2PCS BTS7960 DC Stepper Motor Driver Module 43A Current Limit Control Module H-Bridge PWM Smart Car Board Compatible with Ar duino Raspberry Pi Smart Car by Amazon.co.uk
- • BTS7960 large current (43 A) H bridge driver, 5V power indicator on board; 5V isolate with MCU, and effectively protect MCU.
- • Motor driver module isolated chip 5V power supply (can be shared with the MCU 5V), can also use the on-board 5V supply; the supply voltage 5.5V to 27V.
- • Voltage indication of motor driver output end; can solder heat sink.
- • BTS7960 able to reverse the motor forward, two PWM input frequency up to 25kHZ.
- • High power motor driver module just need four lines from MCU to driver module (GN/ 5V/ PWM1/PWM2), two heat flow passing through an error signal output.
Description
Input Port: RPWM: forward level or PWM signal input, active high LPWM: Reverse level or PWM signal input, active high R_EN: forward drive enable input, high-level enable, low level off L_EN: Reverse drive enable input, high-level enable, low level off R_IS: forward drive current alarm output L_IS: Reverse drive current alarm output VCC: +5 V power output, 5V power supply connection with the microcontroller GND: signal common low end
Package included: 2 x BTS7960 motor drive module
Product information
- Manufacturer:Dorhea
- Part number:14732-1
- Item Weight:160 g
- Package Dimensions:16.1 x 14.9 x 4.3 cm; 160 Grams
- Manufacturer reference:14732-1
- Batteries Required?:No
