Wellue Holter ECG Monitor, Professional 12 Lead ECG Monitors, 24-Hour ECG Holter Record With AI Analysis, Work With Mac & Windows PDF Report Export, Portable Heart Monitor For Home Use by Amazon.co.uk
Description
Many heart conditions are episodic and it can be difficult to detect abnormalities when patients go to hospital for an ECG. Because the ECG recording time is so short, many times it is not possible to monitor the heart for abnormalities.
The Wellue 12-lead Holter ECG monitor makes it easy to record the heart's activity over a 24-hour period. Continuous recording of the ECG is possible both during the day and at night.
The 24-hour ECG monitor not only detects arrhythmias that are normally difficult to detect, but also counts their frequency and specifies their severity.
Note:
Please read the operating card and instructions carefully before using the holter monitor!!!
The default language of the ECG monitor is English.
The package includes operating cards and instructions in English, German, Italian, French and Spanish.
CAPTURING EVERY ECG EVENT WITH AI ANALYSIS
Wellue AI (artificial intelligence-enabled) ECG algorithm, which is based on 300,000 patients and 50 million learning data fragments to analyze data and generate reports. By using clues invisible to the human eye, this AI-ECG Analysis System is able to identify up to 17 kinds of ECG events.
WHAT CAN YOU GET FROM AI-ANALYSIS SYSTEM
On free PC software or Mac App, you can download ECG waveform and detail reports including overview, supraventricular rhythm, ventricular rhythm, HRV, ECG report conclusion, hourly statistics table of ECG data, and ECG Fragment.
The 12 leads will be recorded simultaneously and generated to separate files. Each lead could be selected on the screen as you need. The user can quickly jump to any event via a panel on the left listing the event, it's useful for people to check their result because a typical recording has over 100,000 beats.
Attention:
1.You can download the PC software or the Mac App according to the guidelines on top of the operating card (if you don't know how to download it, please et us know)).
2.If the software pops up with a login screen, please click on "Enter Login" and complete the registration.
3.The AI-ECG should not be used to diagnose or treat disease.
HOW TO RECORD 24 HOUR ECG AND USE THE AI-ECG
Step 1: Install the battery and set the parameters
Use a screwdriver to unscrew the battery clasp, place the battery correctly and screw it back in. The package comes with a screwdriver and 6 batteries. After installing the batteries, the device automatically switches on and enters the settings, setting the current time, date and ID.
Step 2: Place the electrode pads and start ECG recording
First link the ecg leads to the electrode pads and attach the pads to the corresponding positions on the body as instructed by the operating card. If the skin is too dry, wet the skin with water before placing the electrodes. Place the electrode pads and take ECG recordings according to the operating card instructions.
Step 3: End ECG recording and remove the SD card
You can end the ECG recording at any time by pressing both the "Down button" and the "Enter button" on the monitor, or automatically after 24 hours of ECG recording. Once the ECG recording is finished, use a screwdriver to unscrew the battery clasp, remove the battery and gently press on the SD card to eject it.
Step 4: Install the software and use AI-ECG
Install the AI-ECG Analysis System software onto your PC or Mac. Insert the SD card into the card reader and plug the card reader into the PC. Download the ECG records to your PC and click on "Analyse" to carry out the AI analysis. After the analysis is complete you can view the report and export it.After each ECG recording, please download the data to your computer in good time as the SD card is automatically formatted before each ECG recording.
Correct Placement of Electrodes for Recording 8/12 Channel ECGs
Please follow the instructions on the operating card and manual to place the electrodes correctly and ensure that they are firmly attached to the user's skin.
The Wellue ECG monitor has 10 leads, V1, V2, V3, V4, V5, V6, LA, LL, RL and RA, which are differentiated by different colours.
By placing all 10 leads correctly at the same time, 12 channels of ECG can be recorded.
To record an 8-channel ECG, only 6 leads V1, V5, LA, LL, RL, RA need to be placed.
Lightweight and Portable
This palm-sized holter monitor weighs only 2.2 ounces, meaning you can carry it around with you, in your pocket or in your bagvery conveniently.
Shoulder Strap Design
To make continuous ECG recording easier during the day, a holster and shoulder strap have been thoughtfully included. You can carry the monitor in the holster and use the shoulder strap to hang it on your body so that you can record ECG while carrying out your normal activities.
ECG Electrode Pads
The package comes with two packs of 10 electrode pads each, which you can use for ECG recording.
Product information
- Manufacturer:Wellue
- Part number:TH12
- Item Weight:1.01 kg
- Package Dimensions:22.7 x 16.3 x 8.6 cm; 1.01 Kilograms
- Manufacturer reference:TH12
- Batteries included?:Yes
- Batteries Required?:Yes
- Battery Cell Type:Alkaline
