Noctua NH-U9DX i4, Premium CPU Cooler for Intel Xeon LGA20xx (Brown) by Amazon.co.uk
- • Compact single-tower design combines strong cooling performance with excellent case- and PCIe-compatibility
- • 4U compatibility: Only 125mm height is ideal for compact servers and workstations
- • 2 highly optimised NF-B9 92mm fans with PWM support and Low-Noise Adaptors for automatic speed control and ultra-quiet operation
- • Supports both Square ILM and Narrow ILM type LGA20xx (LGA2066, LGA2011-0, LGA2011-3) sockets as well as LGA1356 and LGA1366 based Intel Xeon platforms
- • Includes award-winning NT-H1 thermal compound; Renowned Noctua quality backed up by 6-year manufacturer’s warranty
Compare Noctua NH-U9DX i4, Premium CPU Cooler for Intel Xeon LGA20xx (Brown) with other products:
Description
NH-U series
The NH-U9DX i4 is based on the latest version of Noctua's NH-U9 coolers. First introduced in 2005, the NH-U series has become a standard choice for premium quality quiet CPU coolers.
4U Compatibility
Sporting four heatpipes, a surface area of more than 3800cm\xb2 and two premium grade 92mm fans, the NH-U9DX i4 provides a significant upgrade in quiet cooling performance compared to common 2U solutions. At the same time, its 125mm height makes it fully compatible with standard 4U cases.
SecuFirm2 mounting system
Noctua's SecuFirm2 mounting systems have become synonymous with quality, safety and ease of use. Supporting Intel's LGA2011 (both Square and Narrow ILM), LGA2066, LGA1356 and LGA1366 Xeon platforms, the SecuFirm2 mounting included with the NH-U9DX i4 ensures perfect contact pressure and maximum convenience on all sockets.
2x NF-B9 92mm Premium Fan
The NF-B9 92mm premium fan features Noctua's renowned SSO bearing as well as advanced aerodynamic optimisations such as Bevelled Blade Tips and Vortex-Control Notches. In order to achieve its superb quiet cooling capability, the NH-U9DX i4 comes equipped with two NF-B9 fans in a push/pull setup.
Measurements
Height (without fan): 125 mm
Width (without fan): 95 mm
Depth (without fan): 71 mm
Height (with fan): 125 mm
Width (with fan): 95 mm
Depth (with fan/s): 95/120 mm
Weight (without fan): 428 g
Weight (with fan/s): 550/640 g
Materials
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Cooler Specification
Socket compatibility
For Intel Xeon LGA2011 (Square ILM & Narrow ILM). LGA1356, LGA1366.
2x NF-B9 PWM premium fan
Low-Noise Adaptor (L.N.A.)
NT-H1 high-grade thermal compound
SecuFirm2 Mounting Kit
LGA2066, LGA2011-0 & LGA2011-3
✓
X
✓
X
✓
LGA1700
✓
X
upgrade kit available on request
X
✓
LGA1200, LGA115x (LGA1150, LGA1151, LGA1155, LGA1156)
✓
X
with NM-i115x-1200
X
✓
LGA775 & LGA1366
with NM-I3
X
X
X
with NM-I3
Xeon LGA2011 Narrow ILM / Xeon LGA1366 & LGA1356
X
X
✓
X
X
Xeon LGA3647
X
X
X
X
X
Xeon LGA4189
X
with NM-i4189
X
✓
X
AM5
✓
X
upgrade kit available on request
X
✓
AM4
✓
X
upgrade kit available on request
X
✓
sTRx4, sWRX8, TR4, SP3
X
✓
X
X
X
Product information
- Item dimensions L x W x H:12.5 x 9.5 x 7.1 centimetres
- Brand:Noctua
- Power connector type:4-Pin
- Voltage:12 Volts
- Cooling method:Fan
- Compatible devices:Server
- Noise level:17.6 dB
- Material:Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
- Maximum rotational speed:1600 RPM
- Product Dimensions:12.5 x 9.5 x 7.1 cm; 458.13 Grams
- Item model number:NH-U9DXi4
- Manufacturer:Noctua
- Color:Brown
- Processor Count:1
- Computer Memory Type:DDR3 SDRAM
- Are Batteries Included:No
- Item Weight:458 g
