Compact Wire Connectors,CTRICALVER Electrical Connector Blocks 12 pcs 5 Port Compact Splicing Connectors Lever Nut Assortment Terminal Block Kits and Mounting clip by Amazon.co.uk
Description
More Information About CTRICALVER 12 PCS Compact Wire Connectors
This Wire Connectors 12 pcs Compact Splicing Connectors, 5 Port Electrical Connectors Blocks, with Screws.
This Wire Connectors Quick Splice Solderless Terminals,Instead of traditional electrical tape and electrical butt connectors twist-type,technological innovation reduce wiring time by 70%.
This Wire Connectors is a reusable connector.
This Wire Connectors is widely used in building wiring where space is at a premium for all connections requiring.Can be ideal used in home and automobile applications.
This cable connector has an operating lever, mounting clip,a screw fixing hole, and a power test hole, which is easy to install.
Note:This Wire Connectors product does not have the function of waterproof and moisture-proof, it is only suitable for dry environment
This terminal block matches the wire size
They are suitable for solid wire with 0.08 to 4 mm²/ 28-12AWG (BV), It can connect any combination of solid, stranded and flexible copper wires to meet your different needs. (Note: Please make sure that the power is turned off when working)
HOW TO USE
Move the small lever upward 90 degrees
Remove the 9mm~10mm wire sheath
Insert the cable and restore the small lever.
Compact Wire Connectors feature
The compact wire connectors are ideal for detachable connection and reuse. Just move the small lever up to get there easily
Easy to use and reusable, this product comes with mounting screws (3*16mm), which can be easily fixed on templates and plastic boards.
Choose the best flame retardant insulating material, long life, non-corrosion, anti-aging, withstand voltage 4KV, anti-electric shock.
5-port wire connector, the cable inserted into the cable hole is either +++++, or - - - - -, or EEEEE. Tip:Only the same type of cable can be inserted into each connector
Specification:
Rated voltage: 250V /4KV
Rated current: 32A
Rated power: 7 kW
Applicable wire: 0.08-2.54mm² AWG28-1412
Material of conductive part: electrolytic copper tin plating
Clamping spring: high-alloy nickel-chromium steel
Shell: flame retardant plastic
Notice:
This cable connector is not moisture-proof and waterproof, and can only be used in a dry environment.
Quantity
21 pcs
15 pcs
12 pcs
31 pcs
12 pcs
Applicable wire
0.08-2.54mm²
0.08-2.54mm²
0.08-2.54mm²
0.08-2.54mm²
0.08-2.54mm²
Product information
- Current rating:32 Amps
- Gauge:22.0
- Connector type:Screw
- Number of contacts:5
- Material:Alloy Steel
- Brand:CTRICALVER
- Voltage:250 Volts
- Manufacturer:CTRICALVER
- Part number:M148
- Item Weight:120 g
- Product Dimensions:2.63 x 2.09 x 1.44 cm; 120 Grams
- Manufacturer reference:M148
- Size:PCT-5*12pcs
- Batteries included?:No
- Batteries Required?:No
