Geekworm DACPi for Raspberry Pi 4 Model B, Ultra-thin NUC Aluminum Case with X950 DAC Shield & Heatsink for Pi 4B by Amazon.co.uk
Currently Unavailable
- • Power Requirement5Vdc +/-5% , 3A (Via Type-C of Pi 4);
- • Wifi Description5G WiFi is stable enough, recommend using Ethernet or 5G WiFi due to metal case.
Compare Geekworm DACPi for Raspberry Pi 4 Model B, Ultra-thin NUC Aluminum Case with X950 DAC Shield & Heatsink for Pi 4B with other products:
Description
Geekworm DACPi
is an ultra-thin desktop DAC kit based on the latest raspberry pi 4;
We know that there are many DAC expansion boards released on the market, but there is a common shortcoming that they are too thick. We redesigned the DAC expansion board (X950) and tried our best to make this DAC the thinnest and matched a NUC style aluminum alloy shell, the final thickness of DACPi is only 31mm, hope you will like it.
DACPi adopts modular design, it composed of three parts: X950 DAC Shield, cooling system ( P165-B embedded heatsink), and a ultra-thin NUC style aluminum case; Just simply assemble them with the Raspberry Pi 4 motherboard.
X950 shield
can turn your Raspberry pi 4 into a ready-to-play High Resolution Network Music Player.
DACPi case
is made of all aluminum alloy, CNC processing method
, surface anodizing treatment.
For the cooling solution
, considering that the active cooling fan will interfere with the sound quality, we abandoned the X823-A3 active cooling solution in NASPi, and we only use P165-B(ASIN: B08N617L1J)
to dissipate heat, which can provide enough heat dissipation if there is no overclocking, but P165-B may be a slight impact on WIFI. You can remove the heatsink also.
[Power Supply Requirement]
Power supply: 5Vdc +/-5% , 3A (Via Type-C port of Raspberry pi 4)
Strongly recommended to use raspberry pi official type c power adapter.
[Features]
NUC style shell, thinnest flat design, only 31mm thickness
Use high quality PCM5122 DAC Soluton
Passive heat dissipation, no noise
Powered by the Raspberry Pi PSU- no additional power supply required
Class leading audio: 112db SNR, and THD of 0.0019%
[For Use With]
Raspberry Pi 4 Model B Only
(X950 is compatible with Raspberry pi 3 also, but both DACPi case and P165-B are not compatible with Pi 3)
Operating System: Volumio / OSMC/ Openelec/ Raspbian OS/ Moode Audio Player
[User Guide]
Refer to our WIKI: wiki.geekworm.com/DACPi#User_Manual
[Packing List]
Geekworm DACPi Case
An ultra-thin NUC-style aluminum case for Raspberry Pi 4
X950 DAC Shield
A Raspberry Pi HiFi DAC HAT PCM5122 Audion expansion Board
P165-B Heatsink for Pi 4
P165-B provides the heat dissipation function of DACPi
Product information
- Brand:Geekworm
- Case type:Raspberry Pi
- Colour:Black
- Material:Aluminium
- Cooling method:Air
- Model name:DACPi
- Item weight:121 Grams
- Item dimensions L x W x H:11.2 x 9.1 x 3.1 centimetres
