Noctua NH-L9i, Premium Low-Profile CPU Cooler for Intel LGA115x (Brown) by Amazon.co.uk
Compare Noctua NH-L9i, Premium Low-Profile CPU Cooler for Intel LGA115x (Brown) with other products:
Description
37mm low profile
Due to the slim 23mm heatsink and the NF-A9x14 low profile fan that measures only 14mm in thickness, the NH-L9 stands a mere 37mm tall, which makes it ideal for use in compact HTPCs or Small Form Factor cases that offer minimum clearance for CPU coolers.
100% RAM compatibility
The NH-L9i has a 95x95mm footprint that complies exactly with the Intel LGA115x/1200 socket keep-out zone. This means that it won't cause issues with chipset coolers and doesn't overhang the RAM slots, so it's fully compatible with tall memory modules.
100% compatibility with PCIe cards on mini-ITX
Most Intel LGA115x/1200 based mini-ITX motherboards have the PCIe slot sitting right next to the 95x95mm socket zone. While larger coolers that exceed this zone are likely to block the PCIe slot, the 95x95xmm sized NH-L9i provides full compatibility with PCIe cards.
NF-A9x14 PWM premium fan
The highly optimised NF-A9x14 premium fan features Noctua's proprietary AAO frame as well as sophisticated aerodynamic design measures. Supporting PWM for fully automatic speed control, the NF-A9x14 allows the NH-L9i to stay remarkably quiet.
Measurements
Height (without fan): 23mm
Width (without fan): 95mm
Depth (without fan): 95mm
Height (with fan): 37mm
Width (with fan): 95mm
Depth (with fan): 95mm
Weight (without fan): 320g
Weight (with fan): 380g
Material
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Cooler Specifications
Scope of delivery
NF-A9x14 HS-PWM premium fan
NA-RC7 Low-Noise Adaptor (L.N.A)
NT-H1 high-grade thermal compound
SecuFirm2 mounting kit
Screws for 92x92x25mm fans
Noctua Metal Case-Badge
Fan compatibility
92x92x14mm, 92x92x25mm
Please Note:
The NH-L9i is a highly compact, quiet low-profile cooler designed for use in small form factor cases and HTPC environments. While it provides first-rate performance in its class, it is not suitable for overclocking and or CPUs that create high heat loads.
LGA2066, LGA2011-0 & LGA2011-3
X
X
X
X
X
X
LGA1700
X
✓
X
X
✓
X
LGA1200, LGA115x (LGA1150, LGA1151, LGA1155, LGA1156)
✓
X
X
✓
X
X
LGA775 & LGA1366
X
X
X
X
X
X
Xeon LGA2011 Narrow ILM / Xeon LGA1366 & LGA1356
X
X
X
X
X
X
Xeon LGA3647
X
X
X
X
X
X
Xeon LGA4189
X
X
X
X
X
X
AM2(+), AM3(+), FM1, FM2 (+)
X
X
X
X
X
X
AM4
with NM-AM4-L9aL9i
X
✓
with NM-AM4-L9aL9i
X
✓
sTRx4, sWRX8, TR4, SP3
X
X
X
X
X
X
Product information
- Item dimensions L x W x H:9.5 x 3.7 x 9.5 centimetres
- Brand:Noctua
- Power connector type:4-Pin
- Voltage:12 Volts
- Cooling method:Air
- Compatible devices:Desktop
- Noise level:23.6 dB
- Material:Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
- Maximum rotational speed:2500 RPM
- Product Dimensions:9.5 x 3.7 x 9.5 cm; 417.3 Grams
- Batteries:1 Unknown batteries required.
- Item model number:NH-L9i
- Manufacturer:Noctua
- Color:Brown
- Computer Memory Type:DDR3 SDRAM
- Are Batteries Included:No
- Item Weight:417 g
